Exploded View Part List
REF NO. DESCRIPTION PART NO. Q'TY REMARK
1 FRONT PANEL ASS'Y 703-40USB-1030 1
1-1 FRONT PANEL 300-40USB-1149 1
1-2 KNOB FRAME 100-RMX40-2223 1
1-3 4-8 LED DECORATION 100-RMX40-2232 2
1-4 KNOB PROTECTOR 100-RMX50-1642 1
1-5 SINGLE LED DECORATION 100-RMX50-2207 7
1-6 HIMILON 612-HDJ100-045 6
2 FRONT BOARD ASS'Y 703-40BPM-1037 1
3 MIXER PCB ASS'Y 704-U40-6355 1
4 BOTTOM BASE 300-40USB-1152 1
5 LEVER METER PCB ASS'Y 704-D40-8541 1
6 DSP ADAPTOR PCB ASS'Y 704-U40-6443 1
7 BAL. OUTPUT PCB ASS'Y 704-U40-6352 1
8 USB PCB ASS'Y 704-U40-6356 1
9 AC JACK PCB ASS'Y 704-RMXB50-5227 1
10 INPUT PCB ASS'Y 704-U40-6357 1
11 BEAT SW PCB ASS'Y 704-U40-6354 1
12 PHONE PCB ASS'Y 704-FX19-4398 1
13 MIC PCB ASS'Y 704-U40-6351 1
14 ROTATE KNOB(SEMICIRCLE) 100-SCX2-2211 27
15 ROTATE KNOB 100-RMX40-2211 2
16 POWER KNOB 100-40USB-1641 1
17
PCB HOLDER(MCF-8,H=8mm,ψ4.5,WHITE)
504-B40-185 1
18 PUSH KNOB(LARGE) 100-SCX2-2212 6
19 VR SHEATH 300-SCX2-1125 7
20 FUSE(1A/250V) 422-HDJ7100-022 1
21 POWER SW(SDDLB1017U-HF,2PIN) 403-A100-005 1
22 KNOB 100-RMX40-2222 1
23 VR FIXED PLATE 300-RMX40-1148 5
24 CH VR PCB ASS'Y 704-D40-5294 4
25 FIXING PLATE 300-T1-972 1
26 CROSS FADER PCB ASS'Y 704-D40-5287 1
27 VR CURVE PCB ASS'Y 704-U40-6520 1
28 VR FADER CURVE PCB ASS'Y 704-U40-6521 1
29 SEGREGATE SHEET 501-RMX40-1776 1
30 VR FIXED PLATE 300-RMX40-1151 1
31 SEGREGATE SHEET(SMALL) 501-RMX30-1775 1
32 EFFECT FIXED PLATE(SMALL) 300-RMX30-1139 1
33 TRANSFORMER(AC230V 50HZ/DC 6.3V 1000mA) 411-RMX40-384 1
34 BRACKET TRANSFORMER 300-DV300B-443 2
35 MASTER VR PCB ASS'Y 704-D40-5295 1
36 IC(BA033T/FP 3.3V TO220FP 3PIN) 417-RCC955A-291 1
37 IC(NJM7815FA 3PIN) 417-DV330-216 1
38 IC(NJM7915FA) 417-HV3500K-253 1
39 IC(BA05T,3PIN) 417-CDN34A-314 1
8
