1- The water used for ice machine must be in accordance with local drinking water quality
standards. We recommend installation of an in-line water filter to the ice machine, this will
reduce lime and scale build up, improve efficiency and extend the overall lifespan of the
machine.
2- Water supply pressure should be between 0.2psi and 0.8psi. If pressure exceed 0.8psi, a
pressure reducing device must be used.
3- Water inlet temperature should be between 41°F and 77°F. Faults due to low or high
water pressure and temperature are not covered under warranty.
4- The ice maker drain is gravity flow, make sure the unit is installed above the height of the
drain connector and make sure the hose does not bent to allow for easy draining out.
5- Attach one end of the water inlet hose to the rear of the ice machine, attach the other end
of the hose to the water supply. It is advisable to have a stop valve close to the ice machine.
6- Check both connector washers for a good fit.
7- Put the flexible drain hose on the drain connector at the rear of the machine and secure with
clip provided. The drain pipe can be cut to length to allow drain connection to have a slight fall.
8- It is recommended that the water supply and drain lines be insulated to prevent condensation.
9- Ambient temperature for the ice machine operation should between 41~89.6
°F
.
water
temperature
Water
pressure
Internal diameter
of water inlet pipe
Drain pile
41 ~ 77 °F
0.2psi~0.8psi Internal diameter
3/4 connector
Internal diameter
3/4 connector
Water supply and ambient temperature
