86A-22
V1
MR-453-X79-86A000$100.mif
RADIO
Fault finding chart
86A
ALP 6 Lighting does not change when the vehicle lights are switched on
The radio lighting does not change when the vehicle lights are
switched on.
With the lights on, is there a voltage of approximately 12 V on
connection LPD for left-hand drive or LPG for right-hand
drive of component 261?
Replace the radio (see MR 451,
Mechanical, 86A, Radio,
Radio: Removal - Refitting).
The fault is not associated with the audio equipment.
Check the continuity and insulation of connection LPD for
left-hand drive or LPG for right-hand drive between
components 261 and 1016.
Is the result of the check correct?
Replace the radio (see MR 451,
Mechanical, 86A, Radio,
Radio: Removal - Refitting).
If the connection is faulty and there is a repair procedure
(see Technical Note 6015A, Electrical wiring repair,
Wiring: Precautions for repair), repair the wiring,
otherwise replace it.
YES
NO
YES
NO
