86A-24
V1
MR-453-X79-86A000$100.mif
RADIO
Fault finding chart
86A
ALP 8 The satellite control does not work
The radio works, but the satellite control does not.
Is the satellite control correctly connected?
Reconnect the satellite control and check
that the system operates correctly.
Check the resistances of the satellite control using a
multimeter by running Test 1 Resistance check of
the radio satellite control.
Are the resistances correct?
Replace the satellite control (see MR 451,
Mechanical, 86A Radio, Radio control
satellite: Removal - Refitting).
Check the continuity and insulation of the wiring.
Is the check correct?
Replace the radio (see MR 451, Mechanical, 86A,
Radio, Radio: Removal - Refitting).
NO
YES
NO
YES
NO
YES
