1.50
CHILD SEATS: attachment by seat belt (5/6)
The table below summarises the information already shown on the diagram on the previous page, to ensure the applica-
ble regulations are respected.
Seven-seat version
Type of child seat Weight of the child
Front passenger
seat (1)
Row 2 rear
side seats
Row 2 rear
centre seat
Row 3 rear
centre seat (5)
Carrycot fitted
across the vehicle
Group 0
< 10 kg X U (2) X U
Rear-facing shell
seat
Groups 0 or 0 +
< 10 kg and < 13 kg U (6) U (3) U (3) U
Shell seat/rear-facing
seat
Groups 0+ and 1
< 13 kg and 9 to 18 kg U (6) U (3) U (3) U
Forward-facing seat
Group 1
9 to 18 kg X U (3) (4) U (3) (4) U
Booster seat
Groups 2 and 3
15 to 25 kg and 22 to 36
kg
X U (3) (4) U (3) (4) U
(1) RISK OF DEATH OR SERIOUS INJURY: Before installing a child seat on the front passenger seat, check that
the airbag has been deactivated (please refer to “Child safety: front passenger airbag deactivation and activation” in
Section 1).
