1.104
ENG_UD65159_1
Afficheurs et indicateurs (XFK - Renault)
DISPLAYS AND INDICATORS (6/6)
Instrument panel C
It lights up when the ignition is switched
on. In some cases, the appearance of a
warning light is accompanied by a mes-
sage.
Rev counter 25
(scale x 1,000)
Speedometers 26 and, depending
on the vehicle, 27
(km or miles per hour)
Control your speed according to the ap-
proved speedometer only 26.
The indicator 27 is provided as an in-
dication.
Gear change indicator 28 ➥ 2.21
Overspeed buzzer
Depending on the vehicle and coun-
try, the
warning light is dis-
played and a beep sounds. This beep
sounds as soon as the vehicle is trav-
elling at over 75 mph (120 km/h). This
warning light remains lit for as long as
the vehicle is travelling at over 74 mph
(120 km/h).
Fuel gauge 29
The number of squares lit shows the
fuel level. When it is at minimum, the
squares disappear and the low fuel
level warning light comes on, depend-
ing on the vehicle.
C
25
26
29
27
28
