Rangements / Aménagements habitacle (XFK - Renault)
Tray 24
To remove the parcel shelf, press con-
trol 28 (movement E) and raise the
parcel shelf (movement F).
You can attach documents using the
clamp 29.
You can attach sticky notes to the dedi-
cated area on the clamp 29.
28
E
F
To refit the parcel shelf:
– insert the end 31 of the parcel shelf
into the slot 30;
– press the 28 control (movement E)
and place the parcel shelf in the stor-
age position;
– release the 28 control.
Note: make sure that you refit the
parcel shelf properly and remove any
items from the cup holder before rais-
ing the centre seatback. Check that
the back of the centre seat is properly
locked.
29
Clothes hooks 32
Depending on the vehicle, the hooks
may be located on the ceiling behind
the seats.
For safety reasons, these hooks may
only be used to hang clothes.
Note: the maximum permitted load is
4 kg.
32
PASSENGER COMPARTMENT STORAGE, FITTINGS (7/7)
24
31
30
