Barres de toit modulables (XFK - Renault)
MODULAR ROOF BARS (2/2)
To slide the bar
Roof bar 2 can be slid to move it
closer to or further from the other bar
(figure D).
There are two positions: centre or rear.
With the bar unlocked, pull it towards
the front or the rear of the vehicle to
slide it in rail 3.
Once you have chosen the position,
pivot the bar and lock it in the trans-
verse position (figure E).
Check that both bars are correctly
locked in position.
2
3
D
E
2
When not using the bars in trans-
verse position, refit the bars in lon-
gitudinal position in order to opti-
mise fuel consumption and avoid air
noise.
Check that the objects and/
or accessories (bike rack,
roof box, etc.) fitted to the
roof bars are correctly po-
sitioned, evenly distributed and se-
cured.
