1.36
To rotate the partition
– Unlock the seat base by moving
handle 1 downwards;
– lift the front passenger seat base
vertically (arrow);
– lower headrest 2 to its lowest setting;
– unlock the seatback by moving
handle 1 downwards again and po-
sition the seatback horizontally. To
make the manoeuvre easier, rotate
the headrest 2 ;
– Pivot the moving section 90 degrees,
lock it at point 5 and lower catch 3.
Note: before refitting the swivelling
section in its original position, check
that locking point 4 is clean.
– unlock the swivelling section by lift-
ing catch 3;
– reposition the seat base, proceeding
in reverse order.
The swivelling section must
always be locked when the
vehicle is driven. Risk of
injury.
SWIVELLING PARTITION
When moving the swivelling parti-
tion, ensure the seat belt is not dam-
aged. Hold it aside when you rotate
the partition.
1
2
3
4
5
Maximum weight on the seat in
table position is 80 kg. The weight
must be evenly distributed.
