1.50
The two rings 1 are located between
the seatback and the seat base, behind
the zip fasteners, and are identified by
a marking.
The third ring is used to attach the
upper strap on some child seats.
2
CHILD SAFETY: choosing a child seat mounting (2/3)
Depending on the vehicle, pass the
strap between the wheel arch liner 3
and the underside of the upper parti-
tion 4.
From the luggage compartment, attach
the strap hook to ring 2 on the corre-
sponding side. Check that the bench
seatback is correctly locked.
Pull the belt so that the back of the child
seat comes into contact with the back
of the vehicle seat.
3
4
2
1
Luggage compartment an-
chorages (rings) 2 cannot
be used if they are already
being used to secure two
of the three following components:
luggage net, load in the luggage
compartment or child seat.
