1.54
CHILD SAFETY: fitting a child seat (3/6)
Child seat attached using the belt
¬ Seat which allows a child seat
with “Universal” approval to be attached
by a seat belt.
² Seat not suitable for fitting child
seats.
³ Check the status of the front
airbag before fitting a child seat or al-
lowing a passenger to use the seat.
(1) Before fitting a child seat: position
the vehicle seat as far back as pos-
sible.
Type of seat group
(weight of the child)
Seats suitable for fitting a child seat
Front passenger seat (1)
WITH PASSENGER
AIR BAG (2)
WITHOUT
PASSENGER
AIR BAG
Group 0, 0+
(weight below 13 kg)
UU
Group I
(weight from 9 kg to 18 kg)
UU
Groups II and III
(weight from 15 kg to 36 kg)
UU
(2) RISK OF DEATH OR
SERIOUS INJURY: Before
installing a child seat on the
front passenger seat, check
that the airbag has been deacti-
vated (refer to “Child safety: front
passenger airbag deactivation and
activation” in Section 1).
2-seat version
