FUSES (2/5)
Allocation of fuses (DEPENDING ON THE EQUIPMENT LEVEL)
Numbers Allocation Numbers Allocation Numbers Allocation
î
Radio, heated seats, multi-
function display, sockets for
audio and alarm connec-
tions.
Z
Brake lights, interior lighting.
Cornering lights.
Ä
Passenger compartment
ECU.
Hands-free access.
ë
Accessories sockets.
ß
Brake lights.
£
Tachograph.
Æ
Cigar lighter.
‚
Electric windows, heating
and air conditioning system
and passenger compart-
ment ECU.
y
Heating and air conditioning
system fan.
a
Instrument panel.
8
Left-hand heated rear
screen.
Additional adaptations.
N
Central door control.
7
Right-hand heated rear
screen.
h
Electric windows and pas-
senger compartment ECU.
D
Passenger compartment
ECU, direction indicator
lights and rear fog lights.
l
Windscreen washer.
0
Engine immobiliser.
Î
Diagnostic socket.
ñ
Heated seats.
n
ABS/ESP
