1.17
FRONT HEADRESTS
To remove the headrest
Press button 2 and lift the headrest
to release it.
To lower the headrest
Move tab 1 forwards and lower the
headrest to the required height.
To adjust the angle of the headrest
Depending on the vehicle, tilt
section A towards or away from you
to the required position.
To fit the headrest
Slide it upwards to the required
height.
To refit the headrest
Insert the headrest rods into the
sleeves, with the notches facing
forwards.
Move tab 1 forwards and lower the
headrest to the required height.
The headrest is an important
safety component. Ensure
that it is in place and in the
correct position. The distance
between your head and the
headrest should be as small as
possible. The top of your head
should be in line with the top of
the headrest.
