RL78/G1D RL78/G1D Solution Kit – PMOD Module Hardware Manual
R01AN2919EU0100_RL78G1D Rev. 1.00 Page 6 of 4
Sept. 15, 2015
4. RL78/G1D-SK PMOD Module Design Bill of Material
Table 4 shows the bill of material for RL78/G1D-SK PMOD module.
Table 4 Bill of material for RL78/G1D-SK PMOD module
Item Qty Reference Part Footprint Description Manufacturer Mfg PN
1 3 C1,C2,C10 0.1uF 402 CAP CER 0.1UF 16V
10% X5R 0402
Murata GRM155R61A104KA01D
2 1 C3 0.47uF 402 CAP CER 0.47UF
6.3V 10% X5R 0402
Taiyo Yuden JMK105BJ474KV-F
3 1 C11 10uF 603 CAP CER 10UF 6.3V
20% X5R 0603
Murata GRM188R60J106ME47J
4 1 C9 2.2uF 402 CAP CER 2.2UF 6.3V
10% X6S 0402
Murata GRM155C80J225KE95D
5 2 C5,C6 8pF 402 CAP CER 8PF 50V
NP0 0402
Murata GRM1555C1H8R0DA01D
6 2 C7,C8 9pF 402 CAP CER 9PF 50V
NP0 0402
Murata GRM1555C1H9R0DA01D
7 0 C4 NLC 402 No load capacitor
8 1 E1 W3008 ANTENNA
BT/WLAN/WIFI CER
Pulse W3008
9 1 J2 CON12B CONN HEADER
.100" DUAL R/A
12POS
Sullins PRPC006DBAN-M71RC
10 1 L1 10uH 603 FIXED IND 10UH
50MA 900 MOHM
SMD
Murata LQM18FN100M00D
11 6 R1,R4,R5,
R6,R7,R10
0 402 RES 0.0 OHM 1/16W
0402 SMD
Stackpole RMCF0402ZT0R00
12 3 R2,R8,R9 10K 402 RES 10.0K OHM
1/16W 5% 0402 SMD
Yageo RC0402JR-0710KL
13 1 R3 1K 402 RES 1.00K OHM
1/16W 5% 0402 SMD
Stackpole RMCF0402JT1K00
14 1 R11 6.8 M 402 RES 6.8 M OHM
1/16W 5% 0402 SMD
Yageo RC0402JR-076M8L
15 1 SH1 SHIELD Shield, metal can Custom N/A
16 1 U1 R5F11AGJ QFN-48,
6x6 mm
CPU,BLE,256K,RL78
/G1D
Renesas R5F11AGJANA
17 1 Y1 32MHz 1.2x1.6 Crystal,32MHz
(8pF,20ppm,1.2x1.6)
Abracon ABM12-32.000MHZ-B2X-T3
18 1 Y2 32.768kHz 1.0x1.6 Crystal,32.768kHz
(9pf,20ppm,1.0x1.6)
Abracon ABS05-32.768KHZ-9-T
