5
Probe status LED function
Probe status LED
Blocked beam / probe triggered
Partially blocked beam / probe untriggered
Unblocked beam / probe untriggered
For more information on these LED sequences and modes of operation, see the NC4 separate
non‑contact tool setting system installation and maintenance guide (Renishaw part no. H-4114-8500).
