Renkforce RF-ARA-300 - Overview; Front Panel Identification; Rear Panel Connections

7
7. Overview
1 button
2 F/PS/
button
3 MOD/
button
4 RESET button
5 Display
6 Hands-free microphone
7 SD card reader
8 PWR/MUT button
9
button
10 Knob
11 BND/ID3 button
12 1/
button
13 2/INT button
14 3/RPT button
15 4/RDM button
16 5/
button
17 6/
button
18 AUX port
19 USB port
20 DAB antenna port
21 ISO terminal
22 Fuse
23 LINE outputs
24 FM antenna port
AUX
PWR
MUT
MO D
BND
ID 3
F/PS
5
6
1 2 INT
4 RDM
3 RPT
RESET
1 2 3 4 5 6
7
8
9 10 11 12 13 14 15 16 17 18 19
20
21 22 23 24
