Renogy Core Series User Manual

— 4 —
Mechanical
Properties
Dimensions
Length 198 mm / 7.8 in
Width 165 mm / 6.5 in
Height 169 mm / 6.7 in
Weight 5.35 kg / 11.8 lbs
Housing Material ABS+PC
Terminal Model M8 x 1.25 x 16 mm
Additional Terminal Model M8 x 1.25 x 20 mm
Protection Circuit Module (PCM) Specifications
Battery Operating Status Condition (For Reference Only)
Battery Cell Overvoltage Protection
Trigger Battery Cell Voltage ≥ 3.65V
Recover
Battery Cell Voltage ≤ 3.55V /
Discharge current ≥ 1A
Battery Cell Undervoltage Protection
Trigger Battery Cell Voltage ≤ 2.3V
Recover
Battery Cell Voltage≥2.7V /
Charge current ≥ 1A
Charge High Temperature Protection
Trigger Battery Temperature ≥ 131°F (55°C)
Recover Battery Temperature ≤ 122°F (50°C)
Discharge High Temperature Protection
Trigger Battery Temperature ≥ 149°F (65°C)
Recover Battery Temperature ≤ 131°F (55°C)
Charge Low Temperature Protection
Trigger Battery Temperature ≤ 32°F (0°C)
Recover Battery Temperature ≥ 41°F (5°C)
Discharge Low Temperature Protection
Trigger Battery Temperature ≤ -4°F (-20°C)
Recover Battery Temperature ≥ 5°F (-15°C)
Charge Overcurrent Protection
Trigger Charge current ≥ 65A (Delay 5s)
Recover
Disconnect the charger or
Discharge current ≥ 1A
Discharge Overcurrent Protection
Trigger Disharge current ≥ 165A (Delay 0.5s)
Recover
Disconnect the load or
Charge current ≥ 1A
Short Circuit Protection
Trigger Discharge current ≥ 600A
Recover
Remove Short Circuit (400μs) or
Charge current ≥ 1A
