Renogy E.LUMEN - E.LUMEN Technical Specifications; E.LUMEN Dimensions Diagram

6
Technical Specifications
General
Material Aluminum
Dimensions
Length x Head (diameter) x Body (diameter)
7.83 x 1.65 x 1.22 in
199 x 42 x 31 mm
Weight 0.68 lbs. / 310 g
Protection IP54
Battery
Type 18650 Lithium ion
Capacity 3.7V, 2000mAh
Protection Charging protection, low-capacity protection
Solar
Cell Monocrystalline
Rating 5V, 50mA
Ports
USB Output 5V, 1A Max.
Micro USB Input 5V, 0.55A Max
LED
Headlight 3W, 200 lumens
White Sidelights
2W, 150 lumens
(10 x 0.2W white 2835 SMD LED)
Red Sidelights
Wavelength 620-625
(10 x red 2835 SMD LED)
Lighting Distance 200 meters, headlight
Dimensions
Renogy reserves the right to change the contents of this manual without notice.
Revision: 9/13/2017
