CPU, Memory and Power Supply
Power Rating
Unit
Voltage
Current
Wattage
FP4043
24VDC
140mA
3.36W
FP4070
24VDC
320mA
7.68W
FP4101
24VDC
330mA
7.92W
FP4121
24VDC
420mA
10.08W
FP4151
24VDC
800mA
19.2W
ATTENTION
ATTENTION: Logging to External memory
 The Ethernet models of FP4 series supports SD card slot, which can be used to log
the data directly on SD card. MicroSD HC card with capacity between 4GB to 32GB
is supported. Supported speed classes are as follows:
 While inserting or removing SD card, the device power must be turned off.
 The user must take periodic backup of logged data to avoid loss of data.
CPU: 32-bit RISC processor
eMMC: 4GB
RAM: 512MB
User
Application
Up to 1GB that includes user
application, data log, alarms,
retentive memory and logic
memory
Power Supply:
24VDC (±15%) with isolation
RTC:
Built-in, date and time function
