25
• WATER FUNCTION: To on/o the water function (ventilation with
cooling process) press the button . The green led will lights
showing the function is on. If the green led 9 is continuously on, it
means that the water function is in operation, but the injection pump
is not working.
The green led blinking means that the water function is operating and
the injection pump is working too.
Note: When the fan starts, automatically the water function starts
working.
1 - Remote control IR receiver
2 - Lack of water (yellow) signal lamp
3 - Water injection working signal lamp (green)
4 - Sleep on signal lamp (red)
6 - Sleep programming
5 - On/O water injection
7 - O/Decrease fan speed
8 - On/Increase fan speed
9 - On/o fan (function only in the remote control)
Control Panel / Remote Control Functions
5 3
3
3
• LACK OF WATER: The control panel has a sensor to detect lack of
water inside the tank. When the water level is lower than minimum,
the yellow led starts blinking, informing the user needs to rell the
water tank.
After lling it, the water function will automatically be activated.
Note: When the lack of water is detected, the water function will
stop.
• FAN SPEED: This R6 Control Panel has 10 speeds controlled by the
buttons O/Decrease and On/Increase. The fan is set in the
factory to start at the minimum speed when pressing the button .
You will note that the fan reaches its maximum speed levels when you
hear a longer beep coming from the panel.
REMOTE CONTROL (OPTIONAL): This device has all the Panel
functions as detailed above plus an exclusive command for turning
On/O the fan.
Note: If all the functions are not controlled by the Remote Control,
verify the battery charge. When replacing, use the CR.2025 battery
model.
7
8
8
9
2
