Resolution RE524X - Specifications and Notices; Key Fob Mapping; Product Specifications; Certifications and Notices

“GE”, “INTERLOGIX”, “HONEYWELL”, “DSC”, “2GIG”, “QOLSYS” AND “NAPCO” ARE TRADEMARKS OWNED
BY GENERAL ELECTRIC COMPANY, UNITED TECHNOLOGIES ELECTRONIC CONTROLS INC.,
HONEYWELL INTERNATIONAL INC., TYCO SAFETY PRODUCTS CANADA LTD, NORTEK SECURITY &
CONTROL LLC, TYCO SAFETY PRODUCTS CANADA LTD, AND NAPCO SECURITY TECHNOLOGIES, INC.
RESPECTIVELY.
RESOLUTION PRODUCTS, INC. PRODUCTS WILL FUNCTION WITH ONE OF EITHER INTERLOGIX (FOR-
MERLY GE), HONEYWELL, DSC, 2GIG OR QOLSYS SYSTEMS. HOWEVER, NO RESOLUTION PRODUCT
IS PRODUCED BY, ENDORSED BY, NOR IS OFFICIALLY ASSOCIATED WITH INTERLOGIX (FORMERLY
GE), HONEYWELL, DSC, 2GIG, QOLSYS OR NAPCO. RESOLUTION RECOMMENDS VERIFYING PROPER
ENROLLMENT AND OPERATION, PER CONTROL PANEL INSTALLATION INSTRUCTIONS, AT INSTALLA-
TION.
WARRANTY
RESOLUTION PRODUCTS, INC. WILL REPLACE PRODUCTS THAT ARE DEFECTIVE IN THEIR FIRST FIVE
(5) YEARS.
FCC NOTICE
THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO THE
FOLLOWING TWO CONDITIONS:
(1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE.
(2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE THAT MAY BE RECEIVED, INCLUDING
INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION.
CHANGES OR MODIFICATIONS NOT EXPRESSLY APPROVED BY RESOLUTION PRODUCTS, INC. COULD
VOID THE USER’S AUTHORITY TO OPERATE THIS EQUIPMENT.
FCC ID: U5X-RE524X
IC NOTICE
THIS DEVICE COMPLIES WITH INDUSTRY CANADA LICENSE-EXEMPT RSS STANDARD(S).
OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS:
(1) THIS DEVICE MAY NOT CAUSE INTERFERENCE, AND
(2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE, INCLUDING INTERFERENCE THAT MAY
CAUSE UNDESIRED OPERATION OF THE DEVICE.
LE PRÉSENT APPAREIL EST CONFORME AUX CNR D’INDUSTRIE CANADA APPLICABLES AUX APPAREILS
RADIO EXEMPTS DE LICENCE. L’EXPLOITATION EST AUTORISÉE AUX DEUX CONDITIONS SUIVANTES :
(1) L’APPAREIL NE DOIT PAS PRODUIRE DE BROUILLAGE, ET
(2) L’UTILISATEUR DE L’APPAREIL DOIT ACCEPTER TOUT BROUILLAGE RADIOÉLECTRIQUE SUBI,
MÊME SI LE BROUILLAGE EST SUSCEPTIBLE D’EN COMPROMETTRE LE FONCTIONNEMENT.
IC: 8310A-RE524X
PATENTS
8,456,278
OTHER PATENTS PENDING
Notices
Manual: 47-0014-00 REV A
Date: 15-Feb-16
24-Hour Tech Support Line: (877)260-5578
www.ResolutionProducts.com
Specications
Specications subject to change without notice.
This product is NOT for use with life safety sensors, such as Smoke, Heat, or CO detectors.
PHYSICAL
Housing Dimensions
Weight with Battery
Tamper Activation
Mounting Screws
8.5 x 5.0 x 1.3 inches
16.0 Ounces
Cover Opening
#4 or #6
ENVIRONMENTAL
Operating Temperature
Storage Temperature
Maximum Humidity
32 to 120˚F (0 to 49˚C)
-4 to 86˚F (-20 to 30˚C), Long-Term
85% relative humidity, non-condensing
POWER
Power Transformer
Input
Output
Part Number
Battery
Backup
Specications
Part Number
Trickle Charge
Fast Charge
100-240VAC 50/60Hz 0.5A
12VDC 1A
RE012-6
24 hours minimum
6VDC 800mAh NiMH
RE030
8mA
32mA
WIRELESS RADIO
RF Frequency
Compatibility
319.5MHz, 345MHz, 433.92MHz
Interlogix
® (formerly GE®), 2GIG®
Honeywell®, DSC®, Qolsys®, Napco®
CERTIFICATIONS
ETL Listings
Other
UL 1023, ORD-C1023-1974
FCC, IC
KEY FOB MAPPING
PANEL FUNCTION
KEYFOB
HONEYWELL 2GIG INTERLOGIX DSC NAPCO
HONEYWELL
Off (loop 2)
On (loop 3)
Left (loop 4)
Right (loop 1)
No action
Unlock
Away
Stay
Away+Unlock
Star
Unlock
Lock
Lights
Lock+Unlock
Star
Off
Away
Home
Panic
-
Off
On
Left (A1)
Right (A2)
-
2GIG
Unlock
Away
Stay
Panic (Away+Unlock)
Star
No action
Off
On
Left
Right
-
-
Unlock
Lock
-
Lock+Unlock
Star
Lights
Off
Away
Home
Panic
-
-
Off
On
Left (A1)
Right (A2)
-
-
INTERLOGIX
Unlock
Lock
Lock+Lock
Panic (Lock+Unlock)
No action
Off
On or Left
On
Right
-
Unlock
Away or Stay
Away
Away+Unlock
Star
Off
Away or Home
Away
Panic
-
Off
On or Left (A1)
On
Right (A2)
-
DSC
Off
Away
Home
Panic
No action
Off
On
Left
Right
-
Unlock
Away
Stay
Away+Unlock
Star
Unlock
Lock
Star
Lock+Unlock
Lights
Off
On
Left (A1)
Right (A2)
-
