Channel settings（Band A Set and Band B Set）
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
Zone
GPS
RxGPSInfo
TxGPSInfo
Step
Power
VOX
Vox Level
W/N
TOT
DTMF󶀅Signal
C-CDC
R-CDC
T-CDC
Ch.Name
Busy Lock
Shift Up
Shift Freq
Color Code
Encpt Type
Encpt NO.
DMR Mode
DMR Slot
Promiscuous
RxAll CC
Radio ID
Contacts
GPS contacts
Rx List
Choose the working zone.
Switch GPS on or o. (Only GPS version).
Conrm to receive the GPS information.
Conrm to transmit the GPS information.
Frequency step choose for current channel.
Select power level for current channel.
Turn ON or OFF VOX function.
Choose a VOX working level.
Choose bandwidth for working channel.
Time Out Timer.
Choose if using the DTMF function.
Same RX and TX CTCSS tone, sho press [*scan] button to switch CTCSS, DCS tone and inverse
DCS tone.
Receive CTCSS tone.
Transmit CTCSS tone.
Edit the channel name under channel mode.
Transmit permission settings.
Analog mode: Forbid=Transmit blocked;
=Code represents prohibit transmission when the frequency and sub audio are the same;
Wave represents prohibit transmission as long as there is a channel;
Digital Mode: Impolite: Possible to transmit any time.
Polite to CC: Possible to transmit only if the frequency and CC are the same;
Polite to All: Possible to transmit only when the frequency, CC and Contacts are the same.
Set an oset frequency direction for a repeater channel.
Edit the oset frequency.
Choose a color code for a digital channel.
Choose an encption type.
Choose an encption system.
Choose the working mode for the current digital channel.Simplex, Repeater or Double Slot
Choose DMR slot for current digital channel.
If Promiscuous mode is turned on, then even if the contacts are not correct, the receiver will allow reception
If the RxAll CC mode is turned on, the HD2 will allow reception regardless of the CC being used.
Choose a Radio ID for the current channel.
Choose the communication contacts for the current digital channel.
Choose the transmit and receive GPS contacts.
Receive group list, add or remove contacts from the receive group list.
Other Functions
Message
This menu is mainly set up with SMS related functions:
1)Inbox: Display the received SMS content.
2)Write: edit the message. Edit the text message, long press the [*scan] key to switch between
uppercase and lowercase letters and
numbers.
3)Send Items: Outbox. Check the sent messages, and edit it to resend forward again.
4)Quick text. Edit the quick message text in the CPS, and then choose them on the radio.
Call Log
Check Missed call,Answered call,Outgoing Call.
Contact: priority contact
The HD2 can save 5000 priority contacts on the radio.
1)Enter the [Contacts] menu.
2)Edit the ID, choose the contact type: group, private, or All.
3)Name the contact. Long press[*SCAN] button to switch between ABC, abc, 123.
4)Switch channel knob to edit next contact.
5)In channel band setting, you can choose one of the contacts as your communication
contact.
Radio ID
There can set 32 radio IDs. Edit 32 IDs, and then choose an using ID for a digital channel.
FM radio
32 FM Radio channels can be stored through computer program software;
1)Press the [MENU] key to turn o the radio, or turn on the radio, press [EXIT] to exit.
2)Long press the Exit button to switch between the VFO channel and MR storage channel in
radio mode;
3)Long press the [* Scan] button to save the radio frequency as the radio channel;
4)Sho press the [#] button to turn on or o DW. Dual Watch represents that in FM radio
mode, if there is an intercom signal coming in,
it will rst switch to receiving the intercom signal. If the intercom signal disappears, it will
return to the FM Radio signal.
Version information
Displays the Serial number and rmware version.
Detailed functional operations
1.Save an analog Channel
1)Input 144.25000MHz on Band A or Band B;
2)Press the Menu key to enter Band A or Band B Set;
3)Set the C-CDC and/or the R-CDC. If the C-CDC or the R-CDC is dierent, then set C-CDC
and R-CDC separately.
4)After completing the above operations, it is currently a tempora channel that can be used
for transmission and reception.
5)Enter the Main Set– “Save CH” menu again, select an empty channel to save as a new
channel.
2.Save a digital channel
1)Input 144.25000MHz on Band A or Band B;
2)Long press the Exit button to switch between FM and DMR mode.
3)Select a Color Code;
4)DMR Mode: Simplex;
5)Choose DMR slot;
6)Select the Radio ID to be used for the current channel;
7)Select the call contact for the current channel. Return to the main inteace to edit a
tempora channel for communication;
8)Enter the Main Set– “Save CH” menu again, select an empty channel to save as new
channel.
3.Make an analog repeater channel
1)In VFO mode, input a receiving frequency that is the same as the repeater transmission
frequency;
2)For example, 439.2000MHz is the transmission frequency of the repeater, it will be the
reception frequency of the radio;
3)Enter Band A or B to set the frequency dierence direction, in the Shift Up menu item,
choose “Minus”, and Shift Freq edit 08.0000,
The transmission frequency of the radio is 439.2000-8.0000 MHz, which is 431.20000 MHz;
4)The repeater generally has sub tone settings, Set the same CTCSS tone used by the repeater
on the radio;
5)After completing the above operations, the standby inteace of the radio will display
439.2000Mhz;
6)It will display 431.20000Mhz and the CTCSS when transmitting.
4.Make a digital repeater channel
1)In VFO mode, input a receiving frequency that is the same as the repeater transmission
frequency;
2)For example, 439.2000MHz is the transmission frequency of the repeater, it will be the
reception frequency of the radio;
3)Enter Band A or B to set the frequency dierence direction, in the Shift Up menu item,
choose “Minus”, and Shift Freq edit 08.0000,
The transmission frequency of the radio is 439.2000-8.0000 MHz, which is 431.20000 MHz;
4)Choose a same color code with the repeater color code on the radio Band A or B set.
5)Choose DMR mode “repeater” for a repeater channel.
6)Choose a communication contact for this repeater channel;
7)After completing the above operations, go back to the standby inteace. It will display the
frequency 439.2000Mhz, and DMR icon.
5.Frequency Scan and channel Scan operation
Frequency Scan
1)In the CPS, you can set the sta and end scan frequency for VHF and UHF.
2)Under VFO mode, Sho press [*SCAN] button to begin frequency scan, sholy press
[*SCAN] will stop the frequency scan
