I. Motor wire is connected with motor
1. Green (motor HA)
2. Yellow (motor HB)
3. Blue (motor HC)
4. Red (+5V)
5. Yellow (motor H2)
6. Green (motor H3)
7. Blue (motor H1)
8. Black (ground)
9. White (wheel speed signal)
II. Power wire is connected with the
power
1. Red (36V)
2. Black (ground)
III.
1. Red (+36V)
2. Blue (lock cable)
3. Black (-36V)
4. Green (signal TX)
5. Yellow (signal RX)
6. Purple (5V)
7. Grey (throttle signal SP)
8. White (brake signal BKL)
V. Display wire is connected with the
display
1. Yellow (displayer signal ZF)
2. Green (displayer signal IL)
3. Blue (lock wire)
4. Black (-)
5. Red (+)
V. Brake lever wire is connected with
the brake lever
1. White (brake signal)
2. Black (5V)
VI. Throttle
1. Purple (+5V)
2. Grey (signal)
3. Black (ground)
VII. Power wire of the speed sensor is
connected with the controller
1. Blue (signal)
2. Red (+5V)
3. Black (ground)
12. Main Technical Specication Sheet
Please nd model name of your bike below:
Here is some of the general technical data for this electric bike:
Please nd the crossed technical data regarding the bike motor below:
Please nd the crossed technical data battery and charger below:
Maximum Speed with Electric Assistance:
Motor Type:
Battery Type:
Model
Maximum Output Power:
25km/h ±10%
Brushless with Starry Gears_with Hall
Lithium
Remark (for reference)
500W
36V
Distance per Full Charge:
Maximum Riding Noise:
Voltage:
BEAUMONT REV 36V/350W
Rated Voltage:
36V: 40~50k (total loading ≤75kgs
<60db
36V
13 ± 1A
350W
10.4Ah
31.5V ± 0.5V
Over Current Protection Value:
Rated Power:
Capacity:
Under Voltage Protection Value:
