Figure 7. Installing feet
and spikes.
Figure 8. Installing the
assembled REVEL
PERFORMA PEDESTAL 2
onto the REVEL PERFORMA
C30 loudspeaker.
4. Place the stand (as shown below) and install the feet (from
Step 1) onto the bottom of the ‘T’ base. Thread spikes about
halfway into each foot and use the wrench to tighten each one
with a locking nut, as shown in Figure 7.
5. Place your Revel Performa C30 loudspeaker as shown onto a
carpeted surface or soft towel. Attach the assembled stand with
four 8-32 x 3⁄4" flat head screws, as shown in Figure 8. Turn the
unit upright. Make final placement and spike adjustments.
REVEL PERFORMA C30
Owner’s Manual
9
