REVENT RVM80 - Page 16

15
8.) Once connected, reattach the electrical enclosure.
reattach set
screw
plug in fan
connector
slide
ReVent
®
fan
ReVent
®
switch
120V line AC
black
/red
white
ground
fan’s
electrical
box
black
ReVent
®
FSM-80
product of GTR Technologies Inc.
USA and international patents pending.
Electrical Input: 120 volts @ 60Hz
Maximum Fan Load: 6 Amps
This switch is only to be used with
ReVent fan model RVM80
Must Be Mounted Inside A Code
Approved Electrical Outlet Box
Made In China
