Using gloves, place the rotor onto 6-bolt hub.
While applying a clockwise rotation to the rotor,
tighten the bolts ¼ turn at a time following the
pattern shown. Continue until the bolts are
tightened to 6Nm.
Consult the table to determine if you need
an adapter for your frame or fork. If using an
included Rever adapter, install and torque
fixing bolts to 6–8Nm. If using an adapter from
another manufacturer, install according to the
manufacturer’s specifications.
Loosely install caliper onto the frame, fork,
or adapter.
Install the wheel into the frame and fork per the
manufacturer’s instructions.
INSTALLATION: REVER DISC BRAKE ROTOR
INSTALLATION: REVER DISC BRAKE CALIPER
1 2
1 2
1
3
5
2
6
4
