ANATOMY OF SUPERSYSTEM
04
Station Presets 1 - 10
Media Keys
USB Charging Port
Quick Keys : Direct access buttons to prinipal modes and menus
Touch-Snooze Area
3.5 Headphone Connector
Joystick Controller
Select Button
Power/Standby
Volume Dial
DC Power Socket Aux-In Digital Optical In Digital Optical Out Stereo RCA Connectors Wired LAN Software Update Port Kensington Lock Slot
Telescopic
Antenna
