SECTION
3
Extended
operation
Variable
tape
speed
OUTPUT
CH1
<®
CH2
SPEED
DEVIATION
SLOW
FAST
VARIABLE
elelele
|)
-
+
In
reproduce
as
well
as
record
mode,
the
tape
speed
can
be
varied
by
pressing
the
VARI-
ABLE
[42]
key:
the
yellow
LED
above
this
key
lights
up.
The
deviation
of
the
tape
speed
from
the
se-
lected
nominal
speed
(SLOW/FAST)
can
be
varied
within
the
range
of
-
33%
to
+50
%.
The
tape
speed
can
also
be
varied
externally
via
the
FADER/SYNC
socket
by
means
of
a
TTL
signal
(OV/+5V)
within
the
range
of
-33%
to
+50%.
The
nominal
speed
is
achieved
with
a
control
frequency
of
9.6
kHz.
Pin
1
of
the
connector
is
to
be
connected
to
GND
(OV)
and
the
TTL
signal
to
pin
4.
TTL-Signal
(0...+5V)
Square
wave
fnom
=
9,6
kHz
15
