REVV G50 MK3 - Page 9

REVV | GENERATOR G50 MK3 REVV | GENERATOR G50 MK3
1716
flash & the other LEDs will turn o, this signifies that
MIDI channel 1 has been selected. Simply continue
to press the CH 1 button to get to the channel you
desire. As you press the button, you will notice
the other LEDs turn on as you increase the MIDI
channel number. Once you reach the channel
you desire, press the STORE button to save it to
Memory.
Note: There are only 4 channel LED, so the MIDI
channel count will be done in values of 4. MIDI channel
1 will be signified by CH1 CLEAN LED flashing, & as you
increase in number, MIDI channel 4 will be signified by
all four channel LEDs flashing, but once MIDI channel
5 is selected, only the CH1 CLEAN LED will flash again.
Every time you reach MIDI channel 5, 9, or 13, the LED
cycle will once again start from the CH1 CLEAN LED. So
keep count as you select the channel you desire. If you
go past MIDI channel 16, the count will start at channel
1 again. Once saved to memory, the Channel LEDs will
flash very quickly several times to verify the change has
been made & completed.
MIDI PROGRAM CHANGE
39
This amplifier can remember up to 128 program settings
of the MIDI controllable functions. To set a program (i.e.
amplifier configuration) to be controlled via MIDI:
1. Set the amplifier to the configuration you intend to
save to a program number. (Ex: Ch: 2, Bright ON,
Master Volume: 2, FX Loop: OFF, etc)
2. Once the amplifier is configured as you would like,
press the store button. The Store LED will flash &
the amplifier will wait now for a command through
its MIDI IN jack.
3. Send a program change command from your MIDI
Pedal or other equipment with the correct channel
& program number you intend to have the amplifier.
save the current configuration to.
4. Once the command is received, the amplifier will
save the current amp configuration to that program
number. The Store LED will flash 3 times & turn o
verifying that the command has been received &
Saved.
Now, anytime you send that program number to the amplifier
from your MIDI pedal or other external equipment, the amplifier
will switch to that saved configuration. This will allow for any
configuration of your settings to be recalled with any MIDI device.
MIDI CONTROLLABLE FUNCTIONS
40
The amplifier functions that can be controlled via MIDI
are as follows:
Channel Selection (1-3)
Wide Mode (Ch1)
3 Drive Levels (Ch2)
3 Aggression Levels (Channel 3)
Bright function (All Channels)
Cut function (Channel 3)
Fat function (Channel 3)
FX Loop in/out
Master Volume 1 & 2
Reverb
Noise Gate
Mute
Two Notes Embedded Functions
Noise Gate
Twin Tracker
EQ L
EQ R
Mute
These functions can be set & controlled in a MIDI
program change setting, where one program change
command will call up a configuration of the above
settings, or continuous controller commands, where
a CC command will switch any one of the functions
listed above, independent from any of the others. The
CC command functions are great for things like instant
access buttons on foot pedals etc.
CONTINUOUS CONTROLLER (CC)
41
To use CC commands, the amplifier Functions have
all been given a designated number & on or o
setting. When using & selecting a function the number
associated with the function must be used & then the
setting of the function (on or o) must also be sent. Most
MIDI equipment (pedals etc) allows you to select a CC
number & then designate whether it be turned to on or
o. (Consult the external equipment instruction manual).
The following commands & their CC numbers need only
be sent an ON command (0-63) as they are used to switch
between channels & aggression levels which cannot be
turned o, only changed to a dierent channel or level,
on & o commands sent will produce the same result.
The following 2 commands will switch to the channel
& then toggle through the aggression levels with
each use of the command using the footswitch to
switch to the channel & toggle through the aggression
levels. This command will also respond to an on & o
command with the same result:
Function CC Number Hex value)
Ch. 1 13 - (0x0D)
Ch. 1 Boost 14 - (0x0E)
Ch. 2 15 - (0x0F)
Ch. 2 Boost 16 - (0x10)
The following commands control functions that are
turned on & o. These functions require an o (0-63)
& on (64-127) command (byte) to be sent with the CC
number to either turn them on or o.
If you are trying to use them & are not getting them
to respond, chances are you are sending the wrong
command byte ( 0-63 is OFF & 64-127 is ON).
Function CC Number Hex value)
Noise Gate 26 – (0x1A)
Masters 27 – (0x1B)
Fat 28 – (0x1C)
Bright 29 – (0x1D)
Mute 30 – (0x1E)
Reverb 31 – (0x1F)
Cut 34 – (0x22)
FX Loop 35 – (0x23)
Two Notes Power Amp 36 – (0x24)
Two Notes Reverb 37 – (0x25)
Two Notes Noise Gate 38 – (0x26)
Two Notes Twin Tracker 39 – (0x27)
Two Notes EQ 40 – (0x28)
Two Notes EQ R 41 – (0x29)
Two Notes Mute 42 – (0x2A)
