Table 2 – Rexnord Thomas XTSR52 Coupling Component Part Numbers
Note: the circled numbers identified in the column headers below, correspond to the coupling component numbers in Figures 2 and 3.
XTSR52
Coupling
Size
Adapters

Disc Pack
Part No.
(2 per
Coupling)

Hardware Kit Bolts, Locknuts, and Overload
Bushings for One Disc Pack
12
LH
Part No.
XL
Part No.
XXL
Part No.
Hardware
Kit *
Bolts
Quantity

Locknuts
Quantity

Bushings
Quantity

494
10003209 10003210 10003211
10003753 10611144 4 4 4
644
10003212 --- 10003214
10002803 10611145 4 4 4
726
--- 10001161 10002621
10000091 10001561 6 6 6
826 10000242 10001162 10002622 10000092 10001562 6 6 6
996
10000243 10001163 10002623
10000093 10001563 6 6 6
1088
10000244 10001164 10002624
10000094 10001564 8 8 8
1298 10000245 10001165 10002625 10000095 10001565 8 8 8
1548
10000246 10001166 10002626
10000096 10001566 8 8 8
1698
10000247 10001167 10002627
10000097 10001567 8 8 8
1928 10000248 10001168 10002628 10000098 10001568 8 8 8
2068
10000249 10001169 10002629
10000099 10001569 8 8 8
2278
10000250 10001170 10002630
10000100 10001570 8 8 8
2468 10000251 10001171 10002631 10000101 10001571 8 8 8
2698
10000252 10001172 10002632
10000102 10001572 8 8 8
2888
10000253 10001173 10002633
10000103 10001573 8 8 8
3058 10000254 10001174 10002634 10000104 10001574 8 8 8
3358
10000255 10001175 10002635
10000105 10001575 8 8 8
3668
10000256 10001176 10002636
10000106 10001576 8 8 8
3908 10000257 10001177 10002637 10000107 10001577 8 8 8
4178
10000258 10001178 10002638
10000108 10001578 8 8 8
4588
10000259 10001179 10002639
10000109 10001579 8 8 8
4918 10000260 10001180 --- 10000110 10001580 8 8 8
5258
10000261
--- ---
10000111 10001581 8 8 8
*Disc pack hardware sold as kits only.
