About this documentation 7/60
RE 91616-01-B/10.2014, A6VE Series 65 and 71, Bosch Rexroth AG
1.3.2 Symbols
The following symbols indicate information that is not directly relevant to safety but
increases understanding of the manual.
Table 3: Meaning of the symbols
Symbol Meaning
If this information is disregarded, the product cannot be used or operated
to its optimum potential.
▶
Single, independent step
1.
2.
3.
Numbered instruction:
The numbers indicate that the steps must be completed one after the
other.
1.3.3 Designations
This documentation uses the following designations:
Table 4: Designations
Designation Meaning
A6VE Variable plug-in motor, open and closed circuits
Threaded plug Metal screw, pressure-resistant
Protective plug Made out of plastic, not pressure-resistant, only for transportation
As a generic term for the “variable plug-in motor A6VE” the designation “axial piston
unit” is used in the following.
1.3.4 Abbreviations
This manual uses the following abbreviations:
Table 5: Abbreviations
Abbreviation Meaning
ATEX EU directive on explosion protection (Atmosphère explosible)
BVI Integrated counterbalance valve
DIN Deutsche Industrie Norm (German Institute for Standardization)
EP Proportional control electric
EZ Two point control electric
HA Automatic control, high-pressure related
HP Proportional control hydraulic
HZ Two-point control, hydraulic
ISO International Organization for Standardization
(Internationale Normierungsorganisation)
JIS Japan Industrial Standard
RE Rexroth document in the English language
VDI2230 Directive for the systematic calculation of high duty bolted joints and
joints with one cylindrical bolt from the VDI (VereinDeutscherIngenieure -
Association of German Engineers)
