HORNET PRO
DS-HORNETPRO-4
Technical specifications
Transmitters: FOBBER Transmitter
Enclosure Rating: Standard IP68
Battery Type: CR2032 (supplied)
Battery Life: 2 years @ approx. 50 1/2second presses p/day
Dimensions: 90 x 54 x 27 mm
Changing the Battery: Remove the 2 enclosure screws. replace battery, taking care of contacts and the
battery polarity
Receiver Unit
Enclosure Rating: IP68
Dimensions: 130 x 112 x 42 mm (not including antenna)
Operating Temperature: -10 to +50
o
Celsius.
*The relay contacts in this unit are for functional use only and must not be used for isolation purposes
Electrical Characteristics Min Typical Max Units
Supply Voltage 2.9 3 3.3 V
Supply Current 17 mA
Frequency: 433.92
869.50
MHz
RF Output Power (ERP) - 10 mW
RF Bandwidth 60 KHz
Electrical Characteristics MIN TYPICAL MAX DIMENSION
Supply Voltage for Low Voltage version 11 32 Vdc or ac
Supply Voltage for high Voltage version 230 Vac
Relay Rating* 5 12 A
Supply Current : Quiescent
All (4) relays operating*
25
140
mA
Time delay from Tx on Switch to Rx Relay operation 30 mS
Time delay from Tx sw relax to Rx Relay release
