Point-to-Point/SIK Firmware User Manual
Set new encryption key in hexadecimal characters(e.g. 5A02D5BB...)
Shows current encryption key
Shows GPIO configuration and state
Sets input GPIO pin to mirror on remote radio (local GPIO must be set to input
and remote GPIO pin must be set to output)
Sets output GPIO X to state S
Table 4-1: AT Commands and their description
An example that command will return the local modem’s firmware version string.
ATI
Response
RFD SiK 3.16 on RFD900X R1.3-AU # On a region locked modem
RFD SiK 3.16 on RFD900X R1.3 # On an unlocked modem
Note the letters after the – indicates the modem is locked. The region is indicated by the letters, -AU
Australia, -NZ New Zealand, -US United States of America and Canada, -EU European Union and -IN
India.
Issuing a AT command will take affect only in the local node. A reset ATZ may be required before the
changes will take effect even after a writing the parameters with AT&W.
RT commands are terminal commands that take effect on a remote node. They allow the user to set
or get a remote node’s parameter, for instance, as if they were being set locally.
Shows the firmware version and country code
Shows the firmware version number
Shows all user settable EEPROM parameters and their values
Shows all user settable EEPROM parameters and their possible range
Displays TDM timing report
Displays RSSI signal report
Display Device 64-bit unique ID
Calibration validation test
Displays radio 'S' parameter number ‘n’
Sets radio 'S' parameter number ‘n’ to ‘X’
Displays radio 'R' parameter number ‘n’
Sets radio 'R' parameter number ‘n’ to ‘X’
