Rheem 802V SERIES

31
SIDE RETURN
BOTTOM RETURN
ST-A1220-07-X0
RXGF-CD
ACCESSORY FILTER RACK
FIELD SUPPLIED FILTER
FLANGE WRAPS
AROUND BACK AND
SCREWS TO THE
REAR OF THE
FURNCE, AT THE
LOCATIONS
PROVIDED
CUT OUT USING
EMBOSSED ANGLES
AS A GUIDE
FOR PROPER SIZE
23” X 14”
ST-A1220-07-00
RXGF-CB
$&&(6625<),/7(55$&.
FIELD SUPPLIED FILTER
ST-A1220-06-X0
FIGURE 26
FILTER LOCATIONS
ACCESSORIES
FIELD INSTALLED OPTION ACCESSORIES (cont.)
HORIZONTAL RETURN
ST-A1220-06-00
RXGF-CB ACCESSORY
FILTER RACK
FIELD SUPPLIED FILTER
Accessories
