6
Installation
Warning - All openings in the bottom of the
recess box must be sealed to prevent water inltration
in to the wall. Failure to do so could result in damage
to the wall.
Weather Sealing Recess Box
Drip Ledge
Outer Door
Caulk Joint Between Siding
and Recess Box
Siding or Brick
!
Final Assembly and Inspection
Follow the Use and Care Manual for complete
details about the water heater. Check all water and
gas connections for leaks.
Seal all openings around pipes and wires with an
outdoor grade silicone sealant. Seal the joint between
the recess box and the siding or brick of the house with
a silicone based sealant to prevent water from getting
behind the box into the wall.
Caulk Joint Between Brick and
Recess Box
Seal all openings around pipes and
wires with a silicone sealant
Drip Ledge
Stucco Siding
Flange behind
Stucco Siding
