Operation Manual RHE 07, 08, 11 Page 18
2.1.3.5.2. Analog inputs
The configuration of the analog input corresponds to the setup of the analog outputs.
Choose the desired units for the analog input (0/1-5 volt) from the following units:
V, mA, kg/l, °C, ml/min, m3/min, bar, bara, psi, mPas.
After pressing Next, it is possible to set the input signal range to 1 - 5 Volts or to 0 - 5 Volts. Next
select the lowest and highest values for this range (ie. 0/1 and 5)
Note:
For use as current loop input you have to connect a resistor of 250 Ohm.
example:
250 Ohm
0/4 - 20 mA
current source
