RHEONIK Messgeräte GmbH REV. I, Apr. 2004
.
Operation Manual RHE 07, 08, 11
Page
2
TABLE OF CONTENTS Page
Important safety instructions 4
Installation Quick Guide 5
1. Installation and operation instructions
1.1. General system description 6
1.2.
Installation instructions for sensor RHM 6
1.3.
Wiring sensor RHM 9
1.4.
Mounting instructions RHE flow transmitter 11
1.5.
Power supply wiring 11
2. Operating and programming
2.1. General instructions 12
2.1.1. Keyboard and display 12
2.1.2. Basic operating and programming principle 13
2.1.3. Basic functions
2.1.3.1. Zero calibration 14
2.1.3.2. Reset totalizer 15
2.1.3.3. Display units 15
2.1.3.4. Display sequence and format 16
2.1.3.5. Inputs and outputs
2.1.3.5.1. Current outputs #1 and #2 (analog) 17
2.1.3.5.2. Analog inputs 18
2.1.3.6. Digital inputs and outputs
2.1.3.6.1. Frequency output 19
2.1.3.6.2. Serial communication (interface connection) 20
2.1.3.6.3. External contact inputs 21
2.1.3.6.4. Contact outputs 22
2.1.3.6.5. Configuration of the digital outputs 23
2.1.4. Advanced setup and diagnostics
2.1.4.1. Diagnostics menu 24
2.1.4.1.1. Sensor diagnostics 24
2.1.4.1.2. Sensor basic level programming (BASIS SETUP) 25
3. Error codes 28
4. Warnings 30
5. Troubleshooting guide
5.1. Sensor voltages and resistances 30
5.2.
Temperature calibration 32
