OPERATION
RC456 02/11 Operation Section 4-24
© 2011 Alamo Group Inc.
OPERATION
12.1 Transporting
To transport the machine, it is necessary to raise
the hay rakes which can be done from the tractor
using the hydraulic lever. It is not necessary to
move the hay rakes from the working position in
order to raise them.
When moving a short distance in the field, it is not
necessary to lock the hay rakes; however, when
leaving the field, the safety locks must be used.
While transporting the machine, the safety locks must always be locked, and while
working, the safety locks must always be unlocked.
For safety reasons, after raising the side arms,
attach the chain (55) to the two supports (8) and
(10) by connecting the hooks (56) to pins (T).
The chain must be removed before putting the arms back into the working position.
