STAND ASSEMBLY
2.
1. Remove the four legs and two cross braces from their holders.
Screw each leg into the four corners of the frame. 2. Attach the
cross braces to the inner bars using the thumbscrews , next,
unscrew the lower part of the rear legs and slot in the cross braces.
Retighten the lower part of the rear legs. Flip the stand over. 3. Loosen
the and extend the frame so the straight edge of
the square tube lines up with the point of the arrow . 4. With the help
of another person, set the piano down onto the stand. 5. If placing the
piano on an uneven surface, level the front legs using the adjustable feet.
FRONT
REAR
FRONT - ADJUSTABLE FEET
REAR LEGS
CAUTION! Make sure the stand fits properly
into the recess within the base of the piano.
