SPECIFICATIONS:
DC Output
Maximum DC output voltage
58.8V
Maximum DC output current
15A
Maximum DC output power
850W
Nominal DC output current
15A @ 110VAC, 15A @ 220VAC
Battery type
Lead Acid 48V ONLY
AC Input
AC input voltage range
85-265VAC (With 16AWG IEC C13/C14 Connector)
Nominal AC input voltage
100-240VAC
Nominal AC input frequency
50 / 60Hz
Maximum AC input current
10A~110VAC, 5A~220VAC
Nominal AC input current
6A~110VAC, 3A~220VAC, (Float mode <1A)
Power factor
>0.9pf
Mechanical
Dimensions
L*W*H = 28.2 x 12.97 x 7.3 cm (11.1 x 5.1 x 2.87”)
Weight
7 lbs
（
3.2 kg
）（
Including charger, AC cable only, DC cable separate
）
Cooling
Active cooling with fan
Environmental
Enclosure
IP66
Humidity
5%
－
95%
Operating temperature
-20℃ to +65℃ (-4°F to 149°F)
，
Derated at >40℃ (104℉)
Storage temperature
-40℃ to +85℃ (-40°F to 185°F)
EXPLANATION OF LED STATUS:
LED
Charger Status
1. LED solid green.
The charger is ready to charge, or Charging
is complete.
2. Red or yellow or green light blinks one time per second.
Red light: SOC<80%, Yellow light:
SOC<90%, Green light: SOC<100%
3. Red light blinking quickly.
Input power failure.
4. Red and Green light blinks alternately.
Short circuit or reversed.
5. Red light blinks 2 times, interval 1 second, blinks 2 times again.
Charger temperature over-heating alarm.
6. Red light blinks 3 times, interval 1 second, and then blinks 3 times.
Output over-current alarm.
7. Red light blinks 4 times, interval 1 second, then blinks 4 times.
Output over-voltage alarm.
