Place the intermediate clamp plate and
then top plate to match as shown.
Fit the bottom plate and one bolt with a
nut and washer. Repeat for other three
bolts.
Ensure the unit can slide freely along
the rail of the chassis.
Repeat for the other side motor unit.
Unclip the grey end cap and loosen all
gripping bolts
Slide in centre bar to one motor unit
and slide through to meet the other.
Ensure the unit is centred as shown on
each wheel and make reference to the
centre mark on the centre bar. Allow
clearance all around and make sure
the mover does not catch the tyres.
Tighten all gripping bolts on to
centre bar.
Start to tighten clamp set bolts
ensuring the units remain centred and
use a wooden spacer dowel to set tyre
clearances to 22mm.
Tighten all bolts fully, secure the cable
across the centre bar using the cable
ties.
Feed the control wires up through a
free vent hole in the oor, or drill a
20mm hole in the oor to feed wire
through close to battery box, use cable
clips to secure cables to underside of
caravan oor. If you have drilled right
through the oor use a silicon sealant
to seal the hole.
Connect the electric box as shown,
right and left-hand conventions are
to be followed when you are looking
to the front of the caravan. At this
point please refer to the note below on
tuning control boxes.
Handsets are not tuned in prior to
leaving the works, so please follow the
instructions below:
• Ensure power is on via the red key
switch
• Ensure your handset is switched on
• Press the small button as shown
below
• Keep button pressed and at the
same time press any button on the
handset
• This will immediately tune the
handset to the control box
