SPECIFICATIONS
Product Comparison
Manufacturer: Riata Ranch Company Riata Riata
Models 1108 1110
iMatch Compatible yes yes
Cat. 2 Quick Couple Compatible yes yes
Uses Arena Conditioning and repair tool Arena Conditioning and repair tool
Operating Speed 4-6 mph 4-6 mph
Shipping Single Units Single Units
Frame Tubing Size 3" x 4" x 3/16" 3" x 4" x 3/16"
Max Depth of Workable Footing 6" 6"
Tine Diameter 1" 1"
Tine Length 12" 12"
Tine Composition High Carbon Steel Heat treated High Carbon Steel Heat treated
Number of Tines 21 27
Tines Spacing 2.75" center to center 2.75" center to center
Tine Beam Dimensions 101.5" 77.5"
*Scarier Dimensions 12" Shank, fully disposible 12" Shank, fully disposible
*Scarier Composition 4130 alloy steel 4130 alloy steel
*Number of Scariers 9 11
*Replaceable Scarier tips No No
*Scarier Spacing 10" 10"
*Hydraulic Cylinder Size 11" retracted 11" retracted
*Hydraulic Cylinder Rod & Stroke 1" x 4" 1" x 4"
Gauge Wheels 15" x 6"-6" 15 "x 6"-6"
Working Width (Tines) 76" 98.5"
Working Width (Leveling Comb) 79" 103"
Working Width (Rear Finishing Comb) 94" 117.5"
Machine Width (Transport) 94" 117.5"
Machine Length 55" 55"
Max Working Height 43" 43"
Max Shipping Height 36" w/ pallet 36" w/ pallet
Tractor HP (Min) 30 HP 40 HP
Tractor Width (Max) 76" 98"
Assembly/Set-Up Time 0.7 hr 0.7 hr
3-Point Hitch Cat. I & II Cat. I & II
iMatch Bushing Provided no no
Operating Weight (lbs) 760 950
Shipping Weight (lbs) 800 1000
Warranty 12 Month limited warranty 12 Month limited warranty
SPECIFICATIONS 1
