TABLE SUMMARISING VISUAL AND SOUND ALARMS
SIGNALS DURING PROGRAMMING SEQUENCE
EVENT BUZZER STATUS FLASHER STATUS DL1 LED STATUS
DIP 1 ON (hold-to-run mode)
Or failure of a safety device
OFF OFF Flashes ON/OFF 250 ms
DIP 2 ON (stroke programming) OFF OFF Flashes ON/OFF 500 ms
Programming sequence stopped due to intervention of a safety
device
10 s tone with 2 s pause OFF On steady
EVENT BUZZER STATUS FLASHER STATUS DL12 LED STATUS
No transmitter code entered OFF OFF Flashes red/green
DIP 1 ON > DIP 2 ON - transmitter code programming for full
opening
OFF OFF Flashes red for 10 s
DIP 1 ON > DIP 2 ON > DIP 3 ON - transmitter code programming for
R-AUX relay
OFF OFF Flashes orange for 10 s
Correct transmitter codes programming for opening and R-AUX
relay
1 Tone OFF Turns green once
Remote control code not present in memory OFF OFF Turns red once
Memory saturated by remote control codes (1000 codes saved) OFF OFF Runs 6 green flashes
Radio code deletion for opening and R-AUX relay 2 Tones OFF Runs 2 green flashes
WARNING SIGNALS DURING OPERATION
EVENT BUZZER STATUS FLASHER STATUS LED STATUS AND SIGNAL OUTPUT
Stop button pressed OFF OFF Led DL6 turns OFF
Photocell intervention 1 Tone OFF Led DL7-8 turns OFF
Edge intervention 2 Tones OFF Led DL9 turns OFF
Failure of a safety device or safety device engaged for too long OFF OFF Led DL1 flashes ON/OFF 250 ms
Alarm from edge 2 Tones every 5 s for 1 minute
(It is renewed by giving a command)
Flashes for 1 minute No led combined
Failed photocells auto-test alarm 4 Tones every 5 s for 1 minute
(It is renewed by giving a command)
OFF No led combined
Functional block activated by smartphone OFF OFF Led DL12 is steady on green.
Achievement of set cycles 6 Tones every 5 s
(It is renewed by giving a command)
OFF No leds matched
Energy saving activated by smartphone OFF OFF Blue led flashes once every 5 s
Alarm - no limit switches reached or unlocked barrier 5 Tones Flashes for 1 minute No leds matched
FAULT SOLUTION
After having carried out the various connections and having supplied voltage, all the LEDS are
switched OFF.
On the board there are resettable fuses which intervene in the event of a short circuit,
interrupting the output assigned to them.
In the event of troubleshooting, it is advisable to disconnect all the removable connectors and
insert them one at a time in order to more easily identify the cause of the fault.
Check the integrity of fuse F1.
In case of interrupted fuse use only of adequate value
F1 = T 5A Fuse for motor protection
The motor opens and closes, but it has no strength and moves slowly. Check trimmers LOW SPEED OPEN and LOW SPEED CLOSE adjustment.
The gate opens but does not close after the time set.
Make sure that the TCA trimmer is activated with LED DL11 ON.
B.I.O. contact always on / green led on => check the status of the clock connected to B.I.O.
input.
Photocells Auto-test failed => check the connections between the control panel and the
photocells.
The gate does not close by activating the various START, RADIO and CLOSE buttons.
Faulty safety edge contact. Faulty photocells contact => Fix or replace the faulty contact.
Photocells Auto-test failed => check the connections between the control panel and the
photocells.
By activating the START, OPEN or CLOSE button the barrier does not move.
START, OPEN or CLOSE command always active.
Check and replace any buttons or micro-switches of the selector switch.
The slowing phase is not performed. Check LOW SPEED OPEN e LOW SPEED CLOSE trimmers adjustment.
