RIB NORMAL User Manual

G
B
ACCESSORIES
For the connections and the technical data of the optional equipments follow the relevant handbooks.
Ø 100 mm BOOM ARM
Ø 100 mm boom arm thickness 2 mm need fixing hub L = 6 m.
NOTE: when ordering, the special balance springs should be required (CME8100 for balance
spring Ø 5,5 and CME8068 for balance spring Ø 6).
code ACG8497
L = 6 m
ACG8497 Boom 0 cm
STICKERS FOR Ø 100 BOOM ARM
12 pieces. code ACG8526
STICKERS FOR OCTAGONAL BOOM ARMS
12 pieces. code ACG8527
TELESCOPIC OCTAGONAL BOOM ARM, 6 m
Telescopic octagonal boom arm and fixing hub L = 3 + 3 m.
code ACG8513
TELESCOPIC OCTAGONAL BOOM ARM, 7 m
Telescopic octagonal boom arm and fixing hub L = 4 + 3 m.
code ACG8514
FIXING HUB
Fixing hub for telescopic octagonal boom arm code ACG8564G
FIXING HUB
Fixing hub for ø 100 mm boom arm code ACG8539G
HANGING RACK
L = 2 m code ACG8290
L = 3 m code ACG8291
WARNING: Not to use in windy areas.
N.B. It is obligatory to install an Hanging support ACG8285 or one Fork type support column
ACG9130G.
Maximum 200 daily cycles
BASE PLATE
Base plate. code ACG8110

RIB NORMAL Specifications

General

Motor voltage	24 Vdc
Operating temperature	-20°C to +60°C
Protection level	IP54
Protection Class	IP54
Opening time	6 seconds
Operation Mode	Automatic
Closing Time	6 seconds
Power supply	230V AC
