ELECTRIC CONNECTIONS
GG
BB
CLOSE
OPEN
COMMON
MOTOR
CAPACITOR
M
BLINKER
230Vac 40W
POWER SUPPLY
230Vac 50 Hz
ANTENNA
ANTENNA
BRAIDING
LIMIT SWITCH OPEN
LIMIT SWITCH CLOSE
COMMON
PHOTOCELLS
PEDESTRIAN
OPEN
STOP
STOP
EDGE
CLOSE
STEP BY STEP
24Vdc 0,4A ± 15%
LED
R=2,2K 1/4W
ENCODER
COMMON
SAFETY STRIP
S1 code BC07096
