RIB S1 User Manual

29
29
GG
BB
BUS CONTROLLER
manage devices FIT SLIM BUS and TOUCH BUS LINK 12÷30V ac/dc
code ACG8615
BUS SAFETY SYSTEM
As the name indicates, the BUS SAFETY SYSTEM allows the
continuous connection of all safety strips (both Mechanical or Electrical,
through the TOUCH BUS LINK EN12978 card) and photocells (FIT
SLIM BUS), without having to lay one cable for every component, thus
simplifying the electrical system and saving material and installation
time.
It complies with EN13849-1:2007 Standard, if installed with an RIB
Electronic Board it is a Class-2 Device.
RED - RADIO EDGE DEVICE
RADIO EDGE DEVICE allows to make a system made with edges fixed
to the moving shutter without having to use cable sleeving systems.
It complies with EN13849-1:2007 Standard, if installed with an RIB
Electronic Board it is a Class-2 Device.
FIT SLIM BUS
TO WALL RANGE 20 m SUPPLIED BY BUS CONTROLLER
code ACG8033
PAIR OF COLUMNS FOR FIT SLIM BUS code ACG8065
RADIO TRANSMITTER
for mechanical and electrical strip. code ACG6202
TOUCH EN12978
MECHANICAL STRIP L = 2 m
CERTIFIED EN 12978 (2003-05) CATEGORY EN 954-1 2/3
code ACG3015
RADIO RECEIVER
with container. Suitable for up to 6 Radio Transmitters ACG6202.
code ACG5501
TOUCH BUS LINK
to manage mechanical and electrical strips supplied by BUS
CONTROLLER code ACG8618

RIB S1 Specifications

General

Brand	RIB
Model	S1
Category	Control Unit
Language	English
