Auxiliary Output
1 You can connect your radio to different sources using the auxiliary output.
2 Plug Auxiliary cables (not supplied) into the LINE OUT JACK.
3 Connect the other end of the Auxiliary cables into the input on your desired component.
4 See the owners’ manual for the component for correction operation.
NOTE: The Auxiliary Output is a passive signal level output only and will not power speakers.
Auxiliary Input
1 You can connect external components to your unit by using the Auxiliary Input.
2 Plug Auxiliary cable into the LINE IN JACK on the back of your unit.
3 Set the FUNCTION SWITCH to LINE IN mode
4 Plug the other end of the Auxiliary cable into the output jack on your desired external componet
5 Check the volume level of your external component.
6 See operator’s manual for correct operation of the external component.
Headphone Jack Operation
1 Connect headphones to the Headphone Jack
2 Adjust volume to the desired listening level.
NOTE: When using headphones, the sound to
the unit speakers will be cut off.
NOTE: Headphones not included with unit. The sound from all speakers is cut off
Troubleshooting
There is no Power
1 Make sure radio is plugged in correctly.
2 The unit is not turned on: Rotate the VOLUME ON/OFF KNOB from the OFF
position past the “click” to turn on the unit.
There is no Sound
1 Check the volume level by turning the VOLUME ON/OFF KNOB.
2 Make sure headphones are not connected to the unit.
3 Check the position of the FUNCTION SWITCH.
Turntable will not work
1 Make sure the FUNCTION SWITCH is set to phono.
2 Try moving the tone arm to the right until you hear a click.
3 Make sure the protective needle cover is removed.
Headphone jack
