5
Step 2. Install insert
Use 2pcs M6×16 screws to attach one side
of the insert
Attach another side using same method;
B. Front attachment:
Install insert:
！！！ When inserting the heating unit into mantel; Do not let the bottom of the insert touch the
mantel to avoid scratching it.
GROUNDING
Plug the power supply cord into a wall outlet (220-240Vac,50Hz).The cord has a plug as shown at
A. You should connect as shown below:
Grounding methods
