Repair Parts
For Repair Parts, Call 1-800-4-RIDGID
Please provide following information:
-Model number
-Serial number (if any)
-Part description and number as shown in parts list
Ref. Catalog Part
No Number Number Descriptons Qty
1 17993 BG220901AJ Belt guard assembly (includes 37-45) 1
2 — — Setscrew (included in 27) 1
3 18003 BT023100AV
*
Belt (4L510) 1
4 17703 WL026100AV Filter assembly 1
5— k Screw 4
6—
u Nylon tube 1
7—
u Elbow fitting 2
8 17798 V-215106AV ASME Safety valve 1
9 17783 ST071626AV Torx screw 4
10 18028 ST160002AV
*
Handle grip 2
11 17913 D-1403
*
Drain valve 2
12 17918 ST073612AV Plug 2
13 18033 AR053400OR Tank 1
14 17853 ST158300AV
*
Rubber foot 4
15 18038 ST116400AV Screw 4
16 18043 AA021800AV Axle rod 1
17 18048 ST073613AV Plug 2
18 18053 WA005501AV
*
10" Pneumatic wheel 1
19 18058 CV006412AV
*
Throttle control 1
20 — ST171400AV
*
Throttle unloader 1
21 17878 GA016709AV
*
Gauge, outlet 1
22 17873 HF203300AV
*
Coupler 2
23 17793 WL024501AV
*
Regulator assy. (includes 21, 22 & 24) 1
24 17773 GA016705AV
*
Gauge, tank 1
25 18068 VT470000AV Pump 1
26 18073 ST186600AV Discharge tube 1
27 18078 PU015901AV Flywheel (includes 2) 1
28 18083 PU015400AV Pulley 1
29 18088 KE000900AV 3/16" Key 1
30 18093 ST012200AV Square head setscrew 1
31 18098 BG208800AJ Brace assembly 1
32 18103 NG002502AV Engine 1
33 18108 ST070625AV Hex head screw 4
34 18113 ST011200AV Washer 8
35 18118 AL014000AV Locknut 4
36 18123 ST164100AV Wire retainer 1
37 20978 ST033500AV 3/8” Flange nut 1
38 20983 ST084704AV 3/8” Shoulder bolt 1
39 22788 BG210000AV Beltguard bracket (motor) 1
40 22793 ST070674AV 5/16” - 24 x 1/2” Bolt 1
41 20423 ST016000AV 5/16” - 18 x 3/4” Screw 1
42
18113
ST011200A
V
5/16” Washer 1
43 20428 ST146001AV 5/16” - 18 Nut 1
44
21003
BG220400A
V
Beltguard bracket (pump) 1
45 21008 ST073278AV Beltguard fastener 8
46 22783 ST076829AV M8 - 1.25 x 30 Bolt 1
REPAIR KITS
u 22098 VT273500AJ Tube kit 1
* Considered Wear Items
k Standar
d har
dwar
e item - available at your local har
dwar
e store
