DAMPENING SPRING REMOVAL INSTRUCTIONS
Figure 11 Figure 12
Figure 10
3
TOOLS REQUIRED - Small ate blade screwdriver
1. Make sure the cover support on the left side of the cover is locked so
cover cannot fall (gure 10).
2. Using a small screwdriver, insert the screwdriver blade into the notch
and under the spring clip (gure 11). Pry the clip up until the ball stud
is released, and pull the spring away. (gure 12) Repeat this process
for the bottom clip.
